| ክፍል ቁጥር | LS037V7DD05 |
| የምርት ስም | SHARP |
| መጠን | 3.7 |
| መተግበሪያ | PDA |
| ጥራት | 480×640 |
| ቅንብር | LCM |
| ብሩህነት | 130 |
| CR | 100:1 |
| ቀለሞች | 262K |
| የጀርባ ብርሃን | WLED |
| በይነገጽ | TTL |
| የፓነል ብራንድ | SHARP |
| የፓነል ሞዴል | LS037V7DD05 |
| የፓነል ዓይነት | CG-Silicon , LCM |
| የፓነል መጠን | 3.7 inch |
| መፍታት | 480(RGB)×640 , VGA |
| የማሳያ ሁነታ | TN, Normally White, Transflective |
| ንቁ አካባቢ | 56.16×74.88 mm |
| መዘርዘር | 65×90.4 mm |
| ላዩን | Hard coating (3H) |
| ብሩህነት | 130 cd/m² (Typ.) |
| የንፅፅር ጥምርታ | 100:1 (Typ.)(Transmissive)2.5:1 (Typ.)(Reflective) |
| የማሳያ ቀለሞች | 262K (6-bit), CIE193122% |
| የምላሽ ጊዜ | 20/20 (Typ.)(Tr/Td) |
| የመመልከቻ ማዕዘን | 40/40/40/40 (Typ.)(CR≥2)(L/R/U/D) |
| ድግግሞሽ | 60Hz |
| የመብራት ዓይነት | WLEDWithout Driver |
| የምልክት በይነገጽ | Parallel RGB (1 ch, 6-bit), 61 pins |
| የግቤት ቮልቴጅ | 3.3/5.0/8.0/-4.0/-8.0V (Typ.)(VSHD/VSHA/VDD/VSSD/VEE) |
| ማመልከቻ | PDA |
| LS037V3DX01 | SHARP | 3.7 | 640×480 |
| LS037V3DX02 | SHARP | 3.7 | |
| LS037V7DD05 | SHARP | 3.7 | 480×640 |
| LS037V7DD06 | SHARP | 3.7 | 480×640 |
| LS037V7DD06R | SHARP | 3.7 | 480×640 |
| LS037V7DW01 | SHARP | 3.7 | 480×640 |
| LS037V7DW02 | SHARP | 3.7 | 480×640 |
| LS037V7DW03 | SHARP | 3.7 | 480×640 |
| LS037V7DW03B | SHARP | 3.7 | 480×640 |
| LS037V7DW06 | SHARP | 3.7 | 480×640 |
| LTE283QV-F01 | Samsung | 2.8 | 320×240 |
| LTM035A776B | TOSHIBA | 3.5 | 240×320 |
| NL2432DR22-02B | NLT | 3.5 | 240×320 |
| NL2432DR22-11B | NLT | 3.5 | 240×320 |
| NL2432HC22-22B | NLT | 3.5 | 240×320 |
| NL2432HC22-23B | NLT | 3.5 | 240×320 |
| NL2432HC22-50B | NLT | 3.5 | 240×320 |
| NL4864HL11-01B | NLT | 3.5 | 480×640 |
| TD026TTEA1 | TPO | 2.6 | 480×640 |
| TX09D23VM1CAA | KOE | 3.5 | 240×320 |
