| ክፍል ቁጥር | LA123WF4-SR03 |
| የምርት ስም | LG Display |
| መጠን | 12.3 |
| መተግበሪያ | Automotive Display |
| ጥራት | 1920×720 |
| ቅንብር | a-Si TFT-LCD, LCM |
| ብሩህነት | |
| CR | 800:1 |
| ቀለሞች | 16.7M |
| የጀርባ ብርሃን | WLED |
| በይነገጽ | RSDS |
| የምርት ስም | LG Display |
| ሞዴል | LA123WF4-SR03 |
| ሰያፍ መጠን | 12.3 inch |
| ዓይነት | a-Si TFT-LCD, LCM |
| የፒክሰል ቅርጸት | 1920(RGB)×720 167PPI |
| ማዋቀር | RGB Vertical Stripe |
| ንቁ አካባቢ | 292.032(H)×109.512(V) mm |
| መደብደብ ደበዘዘ። | 310(H)×128(V) ×10.75(D) mm |
| bezel አካባቢ | 296.03(H)×113.5(V) mm |
| ሕክምና | Hard coating |
| ብሩህነት | 600 cd/m² (Min.) |
| የንፅፅር ጥምርታ | 800:1 (Min.) (TM) |
| እይታ አቅጣጫ | Symmetry |
| የምላሽ ጊዜ | 30 (Max.)(G to G); 25 (Typ.)(MPRT) |
| የመመልከቻ ማዕዘን | 89/89/89/89 (Min.)(CR≥10) |
| የክወና ሁነታ | IPS, Normally Black, Transmissive |
| የድጋፍ ቀለም | 16.7M 77% NTSC |
| የብርሃን ምንጭ | WLED [11S4P] , 10K hours , W/O Driver |
| ክብደት | 385/400g (Typ./Max.) |
| የተነደፈ | Automotive Display |
| የፍሬም ፍጥነት | 60Hz |
| የንክኪ ፓነል | Without |
| የበይነገጽ አይነት | RSDS (2 Channel) , 110 pins FPC |
| ገቢ ኤሌክትሪክ | 3.3/13.0V (Typ.)(VCC/VDD) |
| አካባቢ | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
