| ክፍል ቁጥር | BT140GW01 V.0 |
| የምርት ስም | Innolux |
| መጠን | 14.0 |
| መተግበሪያ | NBPC |
| ጥራት | 1366×768 |
| ቅንብር | LCM |
| ብሩህነት | 220 |
| CR | 600:1 |
| ቀለሞች | 262K |
| የጀርባ ብርሃን | WLED |
| በይነገጽ | LVDS |
| የፓነል ብራንድ | INNOLUX |
| የፓነል ሞዴል | BT140GW01 V.0 |
| የፓነል ዓይነት | a-Si TFT-LCD , LCM |
| የፓነል መጠን | 14.0 inch |
| መፍታት | 1366(RGB)×768 , WXGA |
| የማሳያ ሁነታ | TN, Normally White, Transmissive |
| ንቁ አካባቢ | 309.399×173.952 mm |
| መዘርዘር | 323.5×192×5.2 mm |
| የቅርጽ ዘይቤ | Wedge (PCBA Bent, Depth ≥5.2mm) |
| ላዩን | Glare (Haze 0%), Hard coating (3H) |
| ብሩህነት | 220 cd/m² (Typ.) |
| የንፅፅር ጥምርታ | 600:1 (Typ.) |
| የማሳያ ቀለሞች | 262K (6-bit), CIE193160% |
| የምላሽ ጊዜ | 8 (Typ.)(Tr+Td) |
| የመመልከቻ ማዕዘን | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| ድግግሞሽ | 60Hz |
| የመብራት ዓይነት | WLEDEmbedded (LED Driver) |
| የምልክት በይነገጽ | LVDS (1 ch, 6-bit), 40 pins |
| የግቤት ቮልቴጅ | 3.3V (Typ.) |
| ማመልከቻ | NBPC |
